Hey everyone, I've been working on my Reef-Pi project for a few weeks, and I really like the software. It started for me when my LED controller died, and instead of spending $100 on a new one, I was able to use a Pi 2 I had sitting in a drawer. This week I decided I wanted to do a little multitasking with my Pi, and installed Pi Hole for my network. Unfortunately when I installed it, it took over port 80 for it's interface, so I can't get to my Reef-Pi page anymore. Is there a config file I can edit to change the port that the Reef-Pi interface uses? Thanks, this thread has been an awesome source of information.


Tom Bishop

Well-Known Member
Review score
+0 /0 /-0
View Badges
Joined
Jan 1, 2019
Messages
892
Reaction score
1,352
Review score
+0 /0 /-0
Location
Missouri
Hey everyone, I've been working on my Reef-Pi project for a few weeks, and I really like the software. It started for me when my LED controller died, and instead of spending $100 on a new one, I was able to use a Pi 2 I had sitting in a drawer. This week I decided I wanted to do a little multitasking with my Pi, and installed Pi Hole for my network. Unfortunately when I installed it, it took over port 80 for it's interface, so I can't get to my Reef-Pi page anymore. Is there a config file I can edit to change the port that the Reef-Pi interface uses? Thanks, this thread has been an awesome source of information.
You can change either reef-pi via the ui to use 443 or any other port like 8080 etc, and you should be able to do the same for pi-hole. I will say though that while you can combine stuff I would not recommend it, rpi's are cheap and I tend to keep reef-pi by itself but thats a personal decision they can coexist as long as memory and cpu are not an issue.

World Wide Corals

buddy.

Active Member
Review score
+0 /0 /-0
View Badges
Joined
May 16, 2018
Messages
291
Reaction score
617
Review score
+0 /0 /-0
Location
Australia
Great to hear ! What features are you using ?
Ive used most of them over the years, but with my current set up its fairly simple. Temperature, dosing, all equipment controlled by reef-pi, a bunch of timers, auto top off, a bunch of float switches protecting different things, email alerts which have definitely saved my tank at least one time!
I would love a salinity monitor / alert if its ever an option.


Sral

Active Member
Review score
+0 /0 /-0
View Badges
Joined
May 2, 2022
Messages
286
Reaction score
334
Review score
+0 /0 /-0
Location
Germany
Ive used most of them over the years, but with my current set up its fairly simple. Temperature, dosing, all equipment controlled by reef-pi, a bunch of timers, auto top off, a bunch of float switches protecting different things, email alerts which have definitely saved my tank at least one time!
I would love a salinity monitor / alert if its ever an option.
I’ll try to build one myself for my freshwater aquarium. If that works we could try adapting it to saltwater :)


Tom Bishop

Well-Known Member
Review score
+0 /0 /-0
View Badges
Joined
Jan 1, 2019
Messages
892
Reaction score
1,352
Review score
+0 /0 /-0
Location
Missouri
@Ranjib or anyone else know how I can fix the database without starting over, I updated some equipment labels but it must not have liked what I used, not sure if it was the "." but I did a reload and its exited, here is the code:

Aug 13 20:30:39 octopi reef-pi[19740]: panic: descriptor Desc{fqName: "equipment_doser_yellow_1.1ml_h202_dj5_state", help: "Module:equipment Item:Doser Yellow 1.1ml h202 dj5-state", constLabels: {}, variableLabels: []} is invalid: "equipment_doser_yellow_1.1ml_h202_dj5_state" is not a valid metric name


So I just need to fix the equipment label so I can get the website working again, it appears to be functioning but the website is whats not able to come up. I will do some google searching but I think I should be able to fix the equipment labels with out having to restore and rebuild everything. Kicking myself since I been meaning to set up a cron to nightly save a copy of the database, lol. I think I am running version 4.1, thanks.


Tom Bishop

Well-Known Member
Review score
+0 /0 /-0
View Badges
Joined
Jan 1, 2019
Messages
892
Reaction score
1,352
Review score
+0 /0 /-0
Location
Missouri
This is the entry that I think I need to update using the reef-pi db command:

"8": {
"id": "8",
"name": "Doser Yellow 1.1ml h202 dj5",
"outlet": "8",
"on": false

Well I took the easy path and just deleted the ID 8, easy enough to re-create, so here is what I did:

sudo reef-pi db delete equipment 8

Then restarted reef-pi service and this time it started right up, so I assume I cannot use "." in the name/labels? I have a doser that is 1.1ml/min and was trying to use that in the name but I could do 1_1ml.

Last edited:
Top Shelf Aquatics
OP
Ranjib

Ranjib

7500 Club Member
Review score
+0 /0 /-0
View Badges
Joined
Apr 16, 2016
Messages
9,608
Reaction score
16,617
Review score
+0 /0 /-0
Location
Pleasant Hill, Concord
Just here to say that my reef-pi has been running flawlessly this whole time... thanks @Ranjib !!!
thank you for the update. its good to hear things are humming along.

OP
Ranjib

Ranjib

7500 Club Member
Review score
+0 /0 /-0
View Badges
Joined
Apr 16, 2016
Messages
9,608
Reaction score
16,617
Review score
+0 /0 /-0
Location
Pleasant Hill, Concord
This is the entry that I think I need to update using the reef-pi db command:

"8": {
"id": "8",
"name": "Doser Yellow 1.1ml h202 dj5",
"outlet": "8",
"on": false

Well I took the easy path and just deleted the ID 8, easy enough to re-create, so here is what I did:

sudo reef-pi db delete equipment 8

Then restarted reef-pi service and this time it started right up, so I assume I cannot use "." in the name/labels? I have a doser that is 1.1ml/min and was trying to use that in the name but I could do 1_1ml.
hmm.. i have never tried names with period. i cant think of any code that will break due to this.. but i have to test it out


Tom Bishop

Well-Known Member
Review score
+0 /0 /-0
View Badges
Joined
Jan 1, 2019
Messages
892
Reaction score
1,352
Review score
+0 /0 /-0
Location
Missouri
hmm.. i have never tried names with period. i cant think of any code that will break due to this.. but i have to test it out
Here is the output from the journal...

Code:
http2: panic serving 10.99.99.146:52016: descriptor Desc{fqName: "equipment_doser_yellow_1.1ml_dj5_state", help: "Module:equipment Ite
m:Doser Yellow 1.1ml dj5-state", constLabels: {}, variableLabels: []} is invalid: "equipment_doser_yellow_1.1ml_dj5_state" is not a valid metric name
Aug 13 19:57:51 octopi reef-pi[12763]: goroutine 6080056 [running]:
Aug 13 19:57:51 octopi reef-pi[12763]: net/http.(*http2serverConn).runHandler.func1(0x2e68560, 0x33a3fc4, 0x35376c0)
Aug 13 19:57:51 octopi reef-pi[12763]:         /usr/local/Cellar/go/1.14.2_1/libexec/src/net/http/h2_bundle.go:5713 +0x11c
Aug 13 19:57:51 octopi reef-pi[12763]: panic(0x618bc8, 0x310d480)
Aug 13 19:57:51 octopi reef-pi[12763]:         /usr/local/Cellar/go/1.14.2_1/libexec/src/runtime/panic.go:969 +0x118
Aug 13 19:57:51 octopi reef-pi[12763]: github.com/prometheus/client_golang/prometheus.(*Registry).MustRegister(0x2d3f340, 0x310d468, 0x1, 0x1)
Aug 13 19:57:51 octopi reef-pi[12763]:         /Users/ranjib/gocode/pkg/mod/github.com/prometheus/[email protected]/prometheus/registry.go:403 +0x80
Aug 13 19:57:51 octopi reef-pi[12763]: github.com/prometheus/client_golang/prometheus/promauto.Factory.NewGauge(0x7aaff0, 0x2d3f340, 0x0, 0x0, 0x0, 0x0, 0x308a4e0, 0x26, 0x2edf380, 0x32, ...)
Aug 13 19:57:51 octopi reef-pi[12763]:         /Users/ranjib/gocode/pkg/mod/github.com/prometheus/[email protected]/prometheus/promauto/auto.go:297 +0xc0
Aug 13 19:57:51 octopi reef-pi[12763]: github.com/prometheus/client_golang/prometheus/promauto.NewGauge(...)
Aug 13 19:57:51 octopi reef-pi[12763]:         /Users/ranjib/gocode/pkg/mod/github.com/prometheus/[email protected]/prometheus/promauto/auto.go:191
Aug 13 19:57:51 octopi reef-pi[12763]: github.com/reef-pi/reef-pi/controller/telemetry.(*telemetry).EmitMetric(0x2dd8000, 0x6b03ad, 0x9, 0x2dc95e0, 0x1c, 0x0, 0x0)
Aug 13 19:57:51 octopi reef-pi[12763]:         /Users/ranjib/gocode/src/github.com/reef-pi/reef-pi/controller/telemetry/telemetry.go:189 +0x510
Aug 13 19:57:51 octopi reef-pi[12763]: github.com/reef-pi/reef-pi/controller/modules/equipment.(*Controller).updateOutlet(0x2d09e60, 0x31f904f, 0x1, 0x2dc9540, 0x16, 0xbb8070, 0x1, 0x0, 0x0, 0x
0)
Aug 13 19:57:51 octopi reef-pi[12763]:         /Users/ranjib/gocode/src/github.com/reef-pi/reef-pi/controller/modules/equipment/controller.go:83 +0xd8
Aug 13 19:57:51 octopi reef-pi[12763]: github.com/reef-pi/reef-pi/controller/modules/equipment.(*Controller).Update(0x2d09e60, 0x31f904f, 0x1, 0x31f904f, 0x1, 0x2dc9540, 0x16, 0xbb8070, 0x1, 0x
0, ...)
Aug 13 19:57:51 octopi reef-pi[12763]:         /Users/ranjib/gocode/src/github.com/reef-pi/reef-pi/controller/modules/equipment/equipment.go:58 +0xcc
Aug 13 19:57:51 octopi reef-pi[12763]: github.com/reef-pi/reef-pi/controller/modules/equipment.(*Controller).UpdateEquipment.func1(0x31f904f, 0x1, 0x2f6a300, 0x0)
Aug 13 19:57:51 octopi reef-pi[12763]:         /Users/ranjib/gocode/src/github.com/reef-pi/reef-pi/controller/modules/equipment/api.go:166 +0x4c
Aug 13 19:57:51 octopi reef-pi[12763]: github.com/reef-pi/reef-pi/controller/utils.JSONUpdateResponse(0x5d66c0, 0x2f6a300, 0x33a3d00, 0x7ab770, 0x2e68560, 0x32d4d00)
Aug 13 19:57:51 octopi reef-pi[12763]:         /Users/ranjib/gocode/src/github.com/reef-pi/reef-pi/controller/utils/http_json.go:95 +0x124
Aug 13 19:57:51 octopi reef-pi[12763]: github.com/reef-pi/reef-pi/controller/modules/equipment.(*Controller).UpdateEquipment(0x2d09e60, 0x7ab770, 0x2e68560, 0x32d4d00)
Aug 13 19:57:51 octopi reef-pi[12763]:         /Users/ranjib/gocode/src/github.com/reef-pi/reef-pi/controller/modules/equipment/api.go:168 +0x7c
Aug 13 19:57:51 octopi reef-pi[12763]: net/http.HandlerFunc.ServeHTTP(0x2f4c880, 0x7ab770, 0x2e68560, 0x32d4d00)
Aug 13 19:57:51 octopi reef-pi[12763]:         /usr/local/Cellar/go/1.14.2_1/libexec/src/net/http/server.go:2012 +0x34
Aug 13 19:57:51 octopi reef-pi[12763]: github.com/gorilla/mux.(*Router).ServeHTTP(0x2d2f7a0, 0x7ab770, 0x2e68560, 0x34acc80)
Aug 13 19:57:51 octopi reef-pi[12763]:         /Users/ranjib/gocode/pkg/mod/github.com/gorilla/[email protected]/mux.go:210 +0xac
Aug 13 19:57:51 octopi reef-pi[12763]: github.com/reef-pi/reef-pi/controller/utils.(*auth).Authenticate.func1(0x7ab770, 0x2e68560, 0x34acc80)
Aug 13 19:57:51 octopi reef-pi[12763]:         /Users/ranjib/gocode/src/github.com/reef-pi/reef-pi/controller/utils/auth.go:57 +0x294
Aug 13 19:57:51 octopi reef-pi[12763]: net/http.HandlerFunc.ServeHTTP(0x304eb70, 0x7ab770, 0x2e68560, 0x34acc80)
Aug 13 19:57:51 octopi reef-pi[12763]:         /usr/local/Cellar/go/1.14.2_1/libexec/src/net/http/server.go:2012 +0x34
Aug 13 19:57:51 octopi reef-pi[12763]: net/http.(*ServeMux).ServeHTTP(0xbf40b0, 0x7ab770, 0x2e68560, 0x34acc80)
Aug 13 19:57:51 octopi reef-pi[12763]:         /usr/local/Cellar/go/1.14.2_1/libexec/src/net/http/server.go:2387 +0x16c
Aug 13 19:57:51 octopi reef-pi[12763]: net/http.serverHandler.ServeHTTP(0x2d80120, 0x7ab770, 0x2e68560, 0x34acc80)
Aug 13 19:57:51 octopi reef-pi[12763]:         /usr/local/Cellar/go/1.14.2_1/libexec/src/net/http/server.go:2807 +0x88
Aug 13 19:57:51 octopi reef-pi[12763]: net/http.initALPNRequest.ServeHTTP(0x7aca10, 0x2f56dc0, 0x2cf7e00, 0x2d80120, 0x7ab770, 0x2e68560, 0x34acc80)
Aug 13 19:57:51 octopi reef-pi[12763]:         /usr/local/Cellar/go/1.14.2_1/libexec/src/net/http/server.go:3381 +0x5c
Aug 13 19:57:51 octopi reef-pi[12763]: net/http.(*http2serverConn).runHandler(0x35376c0, 0x2e68560, 0x34acc80, 0x3103430)
Aug 13 19:57:51 octopi reef-pi[12763]:         /usr/local/Cellar/go/1.14.2_1/libexec/src/net/http/h2_bundle.go:5720 +0x74
Aug 13 19:57:51 octopi reef-pi[12763]: created by net/http.(*http2serverConn).processHeaders
Aug 13 19:57:51 octopi reef-pi[12763]:         /usr/local/Cellar/go/1.14.2_1/libexec/src/net/http/h2_bundle.go:5454 +0x418

I then changed the 1.1 to 1_1 and its all good now, this was running v4.1..I should always have a backup but this stuff rarely happens since you spoiled us with good code...:)

AND was easy to fix with the DB commands.

Last edited:
First Choice Sale
OP
Ranjib

Ranjib

7500 Club Member
Review score
+0 /0 /-0
View Badges
Joined
Apr 16, 2016
Messages
9,608
Reaction score
16,617
Review score
+0 /0 /-0
Location
Pleasant Hill, Concord
Here is the output from the journal...

Code:
http2: panic serving 10.99.99.146:52016: descriptor Desc{fqName: "equipment_doser_yellow_1.1ml_dj5_state", help: "Module:equipment Ite
m:Doser Yellow 1.1ml dj5-state", constLabels: {}, variableLabels: []} is invalid: "equipment_doser_yellow_1.1ml_dj5_state" is not a valid metric name
Aug 13 19:57:51 octopi reef-pi[12763]: goroutine 6080056 [running]:
Aug 13 19:57:51 octopi reef-pi[12763]: net/http.(*http2serverConn).runHandler.func1(0x2e68560, 0x33a3fc4, 0x35376c0)
Aug 13 19:57:51 octopi reef-pi[12763]:         /usr/local/Cellar/go/1.14.2_1/libexec/src/net/http/h2_bundle.go:5713 +0x11c
Aug 13 19:57:51 octopi reef-pi[12763]: panic(0x618bc8, 0x310d480)
Aug 13 19:57:51 octopi reef-pi[12763]:         /usr/local/Cellar/go/1.14.2_1/libexec/src/runtime/panic.go:969 +0x118
Aug 13 19:57:51 octopi reef-pi[12763]: github.com/prometheus/client_golang/prometheus.(*Registry).MustRegister(0x2d3f340, 0x310d468, 0x1, 0x1)
Aug 13 19:57:51 octopi reef-pi[12763]:         /Users/ranjib/gocode/pkg/mod/github.com/prometheus/[email protected]/prometheus/registry.go:403 +0x80
Aug 13 19:57:51 octopi reef-pi[12763]: github.com/prometheus/client_golang/prometheus/promauto.Factory.NewGauge(0x7aaff0, 0x2d3f340, 0x0, 0x0, 0x0, 0x0, 0x308a4e0, 0x26, 0x2edf380, 0x32, ...)
Aug 13 19:57:51 octopi reef-pi[12763]:         /Users/ranjib/gocode/pkg/mod/github.com/prometheus/[email protected]/prometheus/promauto/auto.go:297 +0xc0
Aug 13 19:57:51 octopi reef-pi[12763]: github.com/prometheus/client_golang/prometheus/promauto.NewGauge(...)
Aug 13 19:57:51 octopi reef-pi[12763]:         /Users/ranjib/gocode/pkg/mod/github.com/prometheus/[email protected]/prometheus/promauto/auto.go:191
Aug 13 19:57:51 octopi reef-pi[12763]: github.com/reef-pi/reef-pi/controller/telemetry.(*telemetry).EmitMetric(0x2dd8000, 0x6b03ad, 0x9, 0x2dc95e0, 0x1c, 0x0, 0x0)
Aug 13 19:57:51 octopi reef-pi[12763]:         /Users/ranjib/gocode/src/github.com/reef-pi/reef-pi/controller/telemetry/telemetry.go:189 +0x510
Aug 13 19:57:51 octopi reef-pi[12763]: github.com/reef-pi/reef-pi/controller/modules/equipment.(*Controller).updateOutlet(0x2d09e60, 0x31f904f, 0x1, 0x2dc9540, 0x16, 0xbb8070, 0x1, 0x0, 0x0, 0x
0)
Aug 13 19:57:51 octopi reef-pi[12763]:         /Users/ranjib/gocode/src/github.com/reef-pi/reef-pi/controller/modules/equipment/controller.go:83 +0xd8
Aug 13 19:57:51 octopi reef-pi[12763]: github.com/reef-pi/reef-pi/controller/modules/equipment.(*Controller).Update(0x2d09e60, 0x31f904f, 0x1, 0x31f904f, 0x1, 0x2dc9540, 0x16, 0xbb8070, 0x1, 0x
0, ...)
Aug 13 19:57:51 octopi reef-pi[12763]:         /Users/ranjib/gocode/src/github.com/reef-pi/reef-pi/controller/modules/equipment/equipment.go:58 +0xcc
Aug 13 19:57:51 octopi reef-pi[12763]: github.com/reef-pi/reef-pi/controller/modules/equipment.(*Controller).UpdateEquipment.func1(0x31f904f, 0x1, 0x2f6a300, 0x0)
Aug 13 19:57:51 octopi reef-pi[12763]:         /Users/ranjib/gocode/src/github.com/reef-pi/reef-pi/controller/modules/equipment/api.go:166 +0x4c
Aug 13 19:57:51 octopi reef-pi[12763]: github.com/reef-pi/reef-pi/controller/utils.JSONUpdateResponse(0x5d66c0, 0x2f6a300, 0x33a3d00, 0x7ab770, 0x2e68560, 0x32d4d00)
Aug 13 19:57:51 octopi reef-pi[12763]:         /Users/ranjib/gocode/src/github.com/reef-pi/reef-pi/controller/utils/http_json.go:95 +0x124
Aug 13 19:57:51 octopi reef-pi[12763]: github.com/reef-pi/reef-pi/controller/modules/equipment.(*Controller).UpdateEquipment(0x2d09e60, 0x7ab770, 0x2e68560, 0x32d4d00)
Aug 13 19:57:51 octopi reef-pi[12763]:         /Users/ranjib/gocode/src/github.com/reef-pi/reef-pi/controller/modules/equipment/api.go:168 +0x7c
Aug 13 19:57:51 octopi reef-pi[12763]: net/http.HandlerFunc.ServeHTTP(0x2f4c880, 0x7ab770, 0x2e68560, 0x32d4d00)
Aug 13 19:57:51 octopi reef-pi[12763]:         /usr/local/Cellar/go/1.14.2_1/libexec/src/net/http/server.go:2012 +0x34
Aug 13 19:57:51 octopi reef-pi[12763]: github.com/gorilla/mux.(*Router).ServeHTTP(0x2d2f7a0, 0x7ab770, 0x2e68560, 0x34acc80)
Aug 13 19:57:51 octopi reef-pi[12763]:         /Users/ranjib/gocode/pkg/mod/github.com/gorilla/[email protected]/mux.go:210 +0xac
Aug 13 19:57:51 octopi reef-pi[12763]: github.com/reef-pi/reef-pi/controller/utils.(*auth).Authenticate.func1(0x7ab770, 0x2e68560, 0x34acc80)
Aug 13 19:57:51 octopi reef-pi[12763]:         /Users/ranjib/gocode/src/github.com/reef-pi/reef-pi/controller/utils/auth.go:57 +0x294
Aug 13 19:57:51 octopi reef-pi[12763]: net/http.HandlerFunc.ServeHTTP(0x304eb70, 0x7ab770, 0x2e68560, 0x34acc80)
Aug 13 19:57:51 octopi reef-pi[12763]:         /usr/local/Cellar/go/1.14.2_1/libexec/src/net/http/server.go:2012 +0x34
Aug 13 19:57:51 octopi reef-pi[12763]: net/http.(*ServeMux).ServeHTTP(0xbf40b0, 0x7ab770, 0x2e68560, 0x34acc80)
Aug 13 19:57:51 octopi reef-pi[12763]:         /usr/local/Cellar/go/1.14.2_1/libexec/src/net/http/server.go:2387 +0x16c
Aug 13 19:57:51 octopi reef-pi[12763]: net/http.serverHandler.ServeHTTP(0x2d80120, 0x7ab770, 0x2e68560, 0x34acc80)
Aug 13 19:57:51 octopi reef-pi[12763]:         /usr/local/Cellar/go/1.14.2_1/libexec/src/net/http/server.go:2807 +0x88
Aug 13 19:57:51 octopi reef-pi[12763]: net/http.initALPNRequest.ServeHTTP(0x7aca10, 0x2f56dc0, 0x2cf7e00, 0x2d80120, 0x7ab770, 0x2e68560, 0x34acc80)
Aug 13 19:57:51 octopi reef-pi[12763]:         /usr/local/Cellar/go/1.14.2_1/libexec/src/net/http/server.go:3381 +0x5c
Aug 13 19:57:51 octopi reef-pi[12763]: net/http.(*http2serverConn).runHandler(0x35376c0, 0x2e68560, 0x34acc80, 0x3103430)
Aug 13 19:57:51 octopi reef-pi[12763]:         /usr/local/Cellar/go/1.14.2_1/libexec/src/net/http/h2_bundle.go:5720 +0x74
Aug 13 19:57:51 octopi reef-pi[12763]: created by net/http.(*http2serverConn).processHeaders
Aug 13 19:57:51 octopi reef-pi[12763]:         /usr/local/Cellar/go/1.14.2_1/libexec/src/net/http/h2_bundle.go:5454 +0x418

I then changed the 1.1 to 1_1 and its all good now, this was running v4.1..I should always have a backup but this stuff rarely happens since you spoiled us with good code...:)

AND was easy to fix with the DB commands.
you are using grafana /prometheus? . is not allowed by prometheus, thats what causing the crash. im bit surprised though, this should not happen as we sanitize the metric name in code,. may be this version didnt had that fix


Tom Bishop

Well-Known Member
Review score
+0 /0 /-0
View Badges
Joined
Jan 1, 2019
Messages
892
Reaction score
1,352
Review score
+0 /0 /-0
Location
Missouri
you are using grafana /prometheus? . is not allowed by prometheus, thats what causing the crash. im bit surprised though, this should not happen as we sanitize the metric name in code,. may be this version didnt had that fix
Yup I am using prometheus/grafna for sure, allows me to keep track of things and really is the dashboard that I use daily vs the reef-pi dashboard. Yeah I'm on a pretty old version, I'm kind of stubborn since if it works and I don't need any of the new features then I tend to stay put. I keep meaning to get my test unit up and working where I can run newer versions but just haven't spent the time to do it. Really wasn't an issue once I figured out what the issue was and gave me an opportunity to use the database command and it worked like a treat. :)

On an another note, I have dosers that are controlled by power outlet relay and looking for a better way to graph in grafana, the state is either on or off and the graph at least the one I am using is time based. I have dosing amounts in the 30s range and would like a better way to capture the data so that I can track it and look at my graph and know its working properly.

If anyone has any suggestions on how to do that in grafana would appreciate the advise. :)

Partner Membership 2023

NeonRabbit221B

2500 Club Member
Review score
+0 /0 /-0
View Badges
Joined
Jun 21, 2019
Messages
3,034
Reaction score
5,592
Review score
+0 /0 /-0
Location
Richmond, Va
Tried upgrading an older version of reef-pi using "wget -c https://github.com/reef-pi/reef-pi/releases/download/5.3/reef-pi-5.3-pi0.deb" followed by "sudo dpkg -i reef-pi-5.3-pi0.deb" and when I run the
sudo systemctl status reef-pi.service command I get this

reef-pi.service - raspberry pi based reef tank controller
Loaded: loaded (/lib/systemd/system/reef-pi.service; disabled; vendor preset:
Active: inactive (dead)
lines 1-3/3 (END)

I tried rebooting and tried it again while running "sudo apt-get remove -y --purge reef-pi" first. Same result....


Schreiber

Leviathan
Review score
+0 /0 /-0
View Badges
Joined
Jun 28, 2016
Messages
469
Reaction score
595
Review score
+0 /0 /-0
Location
Knoxville
@Schreiber wondering if Leviathan 1.1 ORP can be used as Ph. I have your original leviathan, it looks like the main difference is we don’t need to BYOBuckconverters?

Hey there Dan, just now saw this tag!

Yeah, those ports are interchangeable. You can use the ORP input as a 2nd pH input if you'd like!

And yeah, the onboard power conversion is definitely the biggest difference.


NeonRabbit221B

2500 Club Member
Review score
+0 /0 /-0
View Badges
Joined
Jun 21, 2019
Messages
3,034
Reaction score
5,592
Review score
+0 /0 /-0
Location
Richmond, Va
Tried upgrading an older version of reef-pi using "wget -c https://github.com/reef-pi/reef-pi/releases/download/5.3/reef-pi-5.3-pi0.deb" followed by "sudo dpkg -i reef-pi-5.3-pi0.deb" and when I run the
sudo systemctl status reef-pi.service command I get this

reef-pi.service - raspberry pi based reef tank controller
Loaded: loaded (/lib/systemd/system/reef-pi.service; disabled; vendor preset:
Active: inactive (dead)
lines 1-3/3 (END)

I tried rebooting and tried it again while running "sudo apt-get remove -y --purge reef-pi" first. Same result....
Just went through the pain staking process of doing a clean install for the same thing to occur. I also has some issues getting ssh setup... kept giving me a password denied no matter what I did. Even changed keyboard types and tried connecting from my phone.... Im dying here.

Nutramar Foods

Tom Bishop

Well-Known Member
Review score
+0 /0 /-0
View Badges
Joined
Jan 1, 2019
Messages
892
Reaction score
1,352
Review score
+0 /0 /-0
Location
Missouri
Just went through the pain staking process of doing a clean install for the same thing to occur. I also has some issues getting ssh setup... kept giving me a password denied no matter what I did. Even changed keyboard types and tried connecting from my phone.... Im dying here.
This has been touched on and off in the thread but Rob has a good document that walks you through setting things up and there is an initial script that you can run that walks you through the setup - https://docs.google.com/document/d/1t9majBpGlqKacDjkyEZ1HQNWsTRo3woZ/edit

The configuration script can be used for non robotank installs also...

Highly recommended when starting out, should allow you to get things going pretty quickly. :)


NeonRabbit221B

2500 Club Member
Review score
+0 /0 /-0
View Badges
Joined
Jun 21, 2019
Messages
3,034
Reaction score
5,592
Review score
+0 /0 /-0
Location
Richmond, Va
This has been touched on and off in the thread but Rob has a good document that walks you through setting things up and there is an initial script that you can run that walks you through the setup - https://docs.google.com/document/d/1t9majBpGlqKacDjkyEZ1HQNWsTRo3woZ/edit

The configuration script can be used for non robotank installs also...

Highly recommended when starting out, should allow you to get things going pretty quickly. :)
Just frustrating because I have setup like 5-6 of these things and suddenly SSH doesn't seem to want to work. Wondering if its Mac related but I will give it a shot

Thanks!


What's your favorite thing about reef shows? Is it the corals, the cool equipment, the community...?

  • Just getting to be with tons of other reefers! I love the reef community!

    Votes: 4 18.2%
  • Seeing all the awesome equipment!!

    Votes: 1 4.5%
  • Getting to meet some of the reef industry experts and influencers that I've only seen online!

    Votes: 1 4.5%
  • Learning new stuff about the hobby!

    Votes: 2 9.1%
  • Scoring great deals on corals and other livestock!

    Votes: 12 54.5%
  • Looking for those collector pieces that my LFS just doesn't ever have!

    Votes: 1 4.5%
  • Something else... (Comment in the thread)

    Votes: 1 4.5%
Neptune
Top
