Control Your Apex with Siri

[blazeby]

Hi all,

Thanks to a free framework called Homebridge I've been able to control my tank with Siri voice commands.

I find this useful for when my hands are wet and the touch screen on my tablet won't work to turn things on and off via my Apex. Now I just say "Hey Siri, turn off the skimmer" or "Hey Siri, turn off the aquarium alarm".

Homebridge is an open source framework that allows us to add none HomeKit devices to HomeKit and this allow Siri control of those devices.

First thing you need to do is install Homebridge, it's free and instructions are here: https://github.com/nfarina/homebridge

In the Mac terminal: npm install -g homebridge

I used to run it on my Mac but nowadays have it running on a Raspberry Pi - works well on either platform. It also works on Windows machines although I have never tried that.

Next install a Homebridge plug-in called cmdSwitch2 with npm install -g homebridge-cmdswitch2

Now you have to edit your Homebridge config file (config.json) to add the control params for your Apex.

The Apex can be controlled by simple HTTP POST commands and we're going to use them. Your cmdswitch2 entries in your Homebridge config file should look something like this:

"platform": "cmdSwitch2",
"name": "CMD Switch",
"switches": [
{
"name" : "Skimmer",
"on_cmd": "/usr/bin/curl -X POST --user admin:<adminPassword> http://<apexIPaddress>:<apexPortNumber>/status.sht?Skimmer_state=2&Update=Update",
"off_cmd": "/usr/bin/curl -X POST --user admin:<adminPassword> http://<apexIPaddress>:<apexPortNumber>/status.sht?Skimmer_state=1&Update=Update",
}

The state (apexDevice_state) is 0 for Auto, 1 for OFF, and 2 for ON.

And thats it!

Thanks to this thread for the HTTP POST info: https://www.reef2reef.com/threads/guide-how-to-control-neptune-apex-using-google-home.319864/

I may spend sometime to get Siri to be able to report the current state of devices and probes and possibly write a dedicate Apex Homebridge plug-in if time permits.



[Fishlee]

Sounds cool but still too complex for me



[MaddyP]

This is great! Although, it might get more attention in the controller forum than the sponsor forum...

#mods



[blazeby]

That's a very good point!



[bcpitts]

Very nice. Looking forward to more outbid this feature.



[Carlosreef]

Thank you for putting this thread. I just found it so I decided to give it a try. I got it to work correctly using a Raspberry Pi 3 and could not be happier!



[blazeby]

Awesome!



[Carlosreef]

Awesome!

Were you able to ever figure out the HTTP POST for the feed cycles?



[noahreefer]

Dang!!! That’s sick!!



[Joe Carioti]

This looks great! If Homebridge allows for it, you might be able to get outlets or VDM controllability in the Home app as well as controllable by Siri commands.



[Carlos@CoralVue]

This looks great! If Homebridge allows for it, you might be able to get outlets or VDM controllability in the Home app as well as controllable by Siri commands.

Yes, that's how I have it set.



[Joe Carioti]

Yes, that's how I have it set.

Nice! That's super powerful. Do you mind sharing your Homebridge configuration?



[Carlos@CoralVue]

Nice! That's super powerful. Do you mind sharing your Homebridge configuration?

Sure thing...

{
    "bridge": {
        "name": "Homebridge",
        "username": "CC:22:3D:E3:CE:30",
        "port": 123456,
        "pin": "031-45-154"
    },

    "description": "This is an example configuration file with one fake accessory and one fake platform. You can use this as a template for creating your own configuration file containing devices you actually own.",

    "accessory": [],

    "platforms": [
    {
        "platform": "cmdSwitch2",
        "name": "CMD Switch",
        "switches": [
        {
            "name": "Water Change",
            "on_cmd": "/usr/bin/curl -X POST --user <<username>>:<<password>> http://<<ip address>>:<<port>>/status.sht?Return_Pump_state=1&Update=Update",
            "off_cmd": "/usr/bin/curl -X POST --user <<username>>:<<password>> http://<<ip address>>:<<port>>/status.sht?Return_Pump_state=0&Update=Update"
        },
        {
            "name": "Lights",
            "on_cmd": "/usr/bin/curl -X POST --user <<username>>:<<password>> http://<<ip address>>:<<port>>/status.sht?Lights_state=0&Update=Update",
            "off_cmd": "/usr/bin/curl -X POST --user <<username>>:<<password>> http://<<ip address>>:<<port>>/status.sht?Lights_state=1&Update=Update"
        },
        {
            "name": "Skimmer",
            "on_cmd": "/usr/bin/curl -X POST --user <<username>>:<<password>> http://<<ip address>>:<<port>>/status.sht?Skimmer_state=0&Update=Update",
            "off_cmd": "/usr/bin/curl -X POST --user <<username>>:<<password>> http://<<ip address>>:<<port>>/status.sht?Skimmer_state=1&Update=Update"
        },
        {
            "name": "Gyre Left",
            "on_cmd": "/usr/bin/curl -X POST --user <<username>>:<<password>> http://<<ip address>>:<<port>>/status.sht?XF280_Left_state=0&Update=Update",
            "off_cmd": "/usr/bin/curl -X POST --user <<username>>:<<password>> http://<<ip address>>:<<port>>/status.sht?XF280_Left_state=1&Update=Update"
        },
        {
            "name": "Gyre Right",
            "on_cmd": "/usr/bin/curl -X POST --user <<username>>:<<password>> http://<<ip address>>:<<port>>/status.sht?XF280_Right_state=0&Update=Update",
            "off_cmd": "/usr/bin/curl -X POST --user <<username>>:<<password>> http://<<ip address>>:<<port>>/status.sht?XF280_Right_state=1&Update=Update"
        },
        {
            "name": "Smart ATO",
            "on_cmd": "/usr/bin/curl -X POST --user <<username>>:<<password>> http://<<ip address>>:<<port>>/status.sht?ATO_state=0&Update=Update",
            "off_cmd": "/usr/bin/curl -X POST --user <<username>>:<<password>> http://<<ip address>>:<<port>>/status.sht?ATO_state=1&Update=Update"
        },
        {
            "name": "Fans",
            "on_cmd": "/usr/bin/curl -X POST --user <<username>>:<<password>> http://<<ip address>>:<<port>>/status.sht?Cooling_Fans_state=0&Update=Update",
            "off_cmd": "/usr/bin/curl -X POST --user <<username>>:<<password>> http://<<ip address>>:<<port>>/status.sht?Cooling_Fans_state=1&Update=Update"
        },
        {
            "name": "Feed",
            "on_cmd": "/usr/bin/curl -X POST --user <<username>>:<<password>> http://<<ip address>>:<<port>>/status.sht?Feed_state=0&Update=Update",
            "off_cmd": "/usr/bin/curl -X POST --user <<username>>:<<password>> http://<<ip address>>:<<port>>/status.sht?Feed_state=1&Update=Update"
        }
        ]
    }]
}

BTW, I could not figure out the call for FeedX so I ended up creating a virtual outlet that allows me to do the same. The catch is that I have to remember to turn it OFF or the feed will never stop. So if you can figure out the call for FeedA, let me know!



[Joe Carioti]

Sure thing...

{
    "bridge": {
        "name": "Homebridge",
        "username": "CC:22:3D:E3:CE:30",
        "port": 123456,
        "pin": "031-45-154"
    },

    "description": "This is an example configuration file with one fake accessory and one fake platform. You can use this as a template for creating your own configuration file containing devices you actually own.",

    "accessory": [],

    "platforms": [
    {
        "platform": "cmdSwitch2",
        "name": "CMD Switch",
        "switches": [
        {
            "name": "Water Change",
            "on_cmd": "/usr/bin/curl -X POST --user <<username>>:<<password>> http://<<ip address>>:<<port>>/status.sht?Return_Pump_state=1&Update=Update",
            "off_cmd": "/usr/bin/curl -X POST --user <<username>>:<<password>> http://<<ip address>>:<<port>>/status.sht?Return_Pump_state=0&Update=Update"
        },
        {
            "name": "Lights",
            "on_cmd": "/usr/bin/curl -X POST --user <<username>>:<<password>> http://<<ip address>>:<<port>>/status.sht?Lights_state=0&Update=Update",
            "off_cmd": "/usr/bin/curl -X POST --user <<username>>:<<password>> http://<<ip address>>:<<port>>/status.sht?Lights_state=1&Update=Update"
        },
        {
            "name": "Skimmer",
            "on_cmd": "/usr/bin/curl -X POST --user <<username>>:<<password>> http://<<ip address>>:<<port>>/status.sht?Skimmer_state=0&Update=Update",
            "off_cmd": "/usr/bin/curl -X POST --user <<username>>:<<password>> http://<<ip address>>:<<port>>/status.sht?Skimmer_state=1&Update=Update"
        },
        {
            "name": "Gyre Left",
            "on_cmd": "/usr/bin/curl -X POST --user <<username>>:<<password>> http://<<ip address>>:<<port>>/status.sht?XF280_Left_state=0&Update=Update",
            "off_cmd": "/usr/bin/curl -X POST --user <<username>>:<<password>> http://<<ip address>>:<<port>>/status.sht?XF280_Left_state=1&Update=Update"
        },
        {
            "name": "Gyre Right",
            "on_cmd": "/usr/bin/curl -X POST --user <<username>>:<<password>> http://<<ip address>>:<<port>>/status.sht?XF280_Right_state=0&Update=Update",
            "off_cmd": "/usr/bin/curl -X POST --user <<username>>:<<password>> http://<<ip address>>:<<port>>/status.sht?XF280_Right_state=1&Update=Update"
        },
        {
            "name": "Smart ATO",
            "on_cmd": "/usr/bin/curl -X POST --user <<username>>:<<password>> http://<<ip address>>:<<port>>/status.sht?ATO_state=0&Update=Update",
            "off_cmd": "/usr/bin/curl -X POST --user <<username>>:<<password>> http://<<ip address>>:<<port>>/status.sht?ATO_state=1&Update=Update"
        },
        {
            "name": "Fans",
            "on_cmd": "/usr/bin/curl -X POST --user <<username>>:<<password>> http://<<ip address>>:<<port>>/status.sht?Cooling_Fans_state=0&Update=Update",
            "off_cmd": "/usr/bin/curl -X POST --user <<username>>:<<password>> http://<<ip address>>:<<port>>/status.sht?Cooling_Fans_state=1&Update=Update"
        },
        {
            "name": "Feed",
            "on_cmd": "/usr/bin/curl -X POST --user <<username>>:<<password>> http://<<ip address>>:<<port>>/status.sht?Feed_state=0&Update=Update",
            "off_cmd": "/usr/bin/curl -X POST --user <<username>>:<<password>> http://<<ip address>>:<<port>>/status.sht?Feed_state=1&Update=Update"
        }
        ]
    }]
}

Awesome! Thanks Carlos. I had the config.json syntax messed up a bit. I just got this working with my system. That was easier than I expected for sure.



[Joe Carioti]

So, one thing that adds a nice touch here is to populate the "state_cmd" value so Homekit can report back the proper outlet state (on or off). The trick here is how we handle the fact that the cmdSwitch2 library only supports on and off and Apex supports on, off, and auto. Here are the two variations that I can't decide between...

Config 1
Use this configuration to report "ON" when the outlet is in either in AUTO or ON mode (If the outlet is in AUTO-OFF mode, it will report "ON" in Homekit):

"state_cmd": "/usr/bin/curl --fail --silent --show-error --user admin:{{YOUR_APEX_PASSWORD}} http://{{YOUR_APEX_IP}}:{{YOUR_APEX_PORT}}/cgi-bin/status.xml | grep -i '<name><{{YOUR_APEX_OUTLET_NAME}}</name>' -A2 | grep -E -i 'AO|ON'"

I prefer this config because I rarely ever turn my outlets to full ON. I always consider OFF = OFF and ON = AUTO. So when the outlet is in AUTO mode, I want Homekit to tell me that the outlet is turned ON.


Config 2
Use this configuration to report "ON" if the outlet is getting electrical power (If the outlet is in AUTO-OFF mode, it will report "OFF" in Homekit):

"state_cmd": "/usr/bin/curl --fail --silent --show-error --user admin:{{YOUR_APEX_PASSWORD}} http://{{YOUR_APEX_IP}}:{{YOUR_APEX_PORT}}/cgi-bin/status.xml | grep -i '<name><{{YOUR_APEX_OUTLET_NAME}}</name>' -A2 | grep -i 'ON'"

This configuration might be what you guys would expect to see. If your skimmer is turned on by any means (ON, or AUTO-ON), you'll see "ON" in HomeKit. If your skimmer is turned off by any means (OFF, or AUTO-OFF), you'll see "OFF" in HomeKit.



[Carlos@CoralVue]

I think Config 1 makes total sense to me. That is how I have some of my switches set. At the end of the day, this is for me and not someone else. I understand the logic of it and it is something that makes sense.

The only issue I see is if something is set to OFF automatically. Like the fans... The fans could be set to AUTO but the default state is OFF. That is where this would get a little tricky.



[Carlos@CoralVue]

Love it when things come together!!!



[blazeby]

You guys have done a great job! I use a combo of config 1 and config 2 depending on whether or not Auto is set to ON or OFF.

For the FeedX not turning off problem this is where HomeKit will help you out - you can set a timer to automatically turn a device on or off via the Home app.



[Joe Carioti]

You guys have done a great job! I use a combo of config 1 and config 2 depending on whether or not Auto is set to ON or OFF.

For the FeedX not turning off problem this is where HomeKit will help you out - you can set a timer to automatically turn a device on or off via the Home app.

Great idea. I might look into forking that cmd2switch library to allow for on, off, and auto states. It would need a different UI than the standard HomeKit “switch” UI. I’ll report back if I find anything useful.



[blazeby]

Thinking about forking it myself to provide temperature sensor support so we can retrieve temp, pH, ORP etc via Homebridge.
