totally missed that Harry posted his board haha. The diagram above is just that circuit he has laid out.
Harry and I did some work on what resistors are needed for this. It’s not as straight forward as it seems since they have some input protection on the input pin that throws off the resistor calculations. The following has been tested and works with hydros. And it also uses the 5V output already available on the 0-10v input connector.
