Durso Or Stockman Standpipe? Wow! What A Difference!?

I decided to finally quiet down my CPR CS90 overflow after years of the gurgling and sucking sound in the background. Wow! What a difference!? It...
  1. jsker

    jsker Reefing is all about the adventure Staff Member Team R2R R2R Supporter R2R Excellence Award Partner Member 2019 R2R Secret Santa Reef Tank 365 Build Thread Contributor Article Contributor

    Joined:
    Apr 11, 2015
    Messages:
    18,668
    Likes Received:
    34,579
    Location:
    Central Florida
    I decided to finally quiet down my CPR CS90 overflow after years of the gurgling and sucking sound in the background. Wow! What a difference!? It only took about 10 minutes to build. Since I had to wait 24 hours for the glue to dry right for safety for the system, after building the Durso. I decided to use the Stockman standpipe first because no glue is needed.

    Doing research, I found the Durso type standpipe first (LINK). I watched a couple of videos and decided to give it a try. A few hours later, I started putting my parts list together, then I discovered this thread here on R2R (LINK). I read through the thread, and it was suggested that the Stockman standpipe is quieter than the Durso standpipe. Then, I found a video on how to make a Stockman standpipe. I decided to stay with the Stockman standpipe because it worked.

    Parts list for the Durso:

    1” schedule 40 PVC 5” long cut in half, so that there is 2 x 2.5” sections, making sure the air intake is 1” above the overflow in the back the overflow box.

    1” T-fitting

    1” Street 90

    1” Cap

    A saw or PVC cutter, PVC glue, and a 13/64 drill bit for the air inlet hole.

    One can adjust the flow by sticking some air line in the air inlet hole with an adjustable air line fitting

    Picture of air line adjuster


    Picture of stand pipe


    Parts list for the Stockman

    1” schedule 40 PVC cut 7.5 inches long, making sure the air intake is 1” above the overflow in the back the overflow box.

    1” repair compression coupling just for the rubber washer.

    1 ¼ “coupling to fit over washer and drilled holes

    1” cap

    13/64 drill bit for air inlet hole

    15/16 drill bit for water intake holes

    Air line and air line adjustment fitting

    I measured up two inches up from the bottom and made a line. Then measured up another inch to where my washer will be. I drilled 5/16 holes in the one-inch section randomly to let the water into the pipe. Slide the 1 ¼ fitting down over the washer to the two-inch mark. Drill a 13/64 hole in the top cap, push in your airline and adjuster. Place in overflow and adjust the flow with the airline adjuster. It will take a couple of tweaks but wow what a difference.

    Picture of Stockman


    Video of the noise reduction

    Last edited: Jun 10, 2018
    Tags:

  2. Crabs Mcjones

    Crabs Mcjones Millepora Maniac Staff Member Team R2R R2R Supporter R2R Excellence Award Partner Member 2019 R2R Secret Santa Reef Tank 365 Build Thread Contributor Article Contributor Hospitality Award

    Joined:
    Jul 24, 2017
    Messages:
    15,849
    Likes Received:
    59,203
    Location:
    Fond du Lac, Wisconsin
    Night and day difference! Great job ;)

    GoVols, DSC reef, Fudsey and 2 others like this.
  3. jsker

    jsker Reefing is all about the adventure Staff Member Team R2R R2R Supporter R2R Excellence Award Partner Member 2019 R2R Secret Santa Reef Tank 365 Build Thread Contributor Article Contributor

    Joined:
    Apr 11, 2015
    Messages:
    18,668
    Likes Received:
    34,579
    Location:
    Central Florida
    Very simple, thank you:)

  4. siggy

    siggy Gone Fishing Again R2R Supporter R2R Excellence Award Partner Member 2019 R2R Secret Santa Build Thread Contributor

    Joined:
    Feb 16, 2017
    Messages:
    3,508
    Likes Received:
    6,692
    Location:
    Chesterfield Michigan
    That worked well, After a year of running mine has gotten quite loud and the vent is whistling like a tea pot, not really but is making a sucking noise. and Ill have to do something to correct. Marine land with a single stand pipe.
    any suggestions?

  5. Fudsey

    Fudsey Jack of all trades R2R Supporter R2R Excellence Award Reef Squad Reef Tank 365 Build Thread Contributor NHFS Member

    Joined:
    May 7, 2016
    Messages:
    6,118
    Likes Received:
    25,623
    Location:
    So. New Hampshire
    My 72 bow had the same pipe @siggy Make sure the vent is clear. I used to use a pipe cleaner to clean mine out occasionally.

    I bought a few like this

    [​IMG]

    GoVols, jsker, siggy and 1 other person like this.
  6. siggy

    siggy Gone Fishing Again R2R Supporter R2R Excellence Award Partner Member 2019 R2R Secret Santa Build Thread Contributor

    Joined:
    Feb 16, 2017
    Messages:
    3,508
    Likes Received:
    6,692
    Location:
    Chesterfield Michigan
    Thanks, that is better than the cordless roto-ruter I had in mind:confused:

    GoVols, Fudsey, jsker and 1 other person like this.
  7. jsker

    jsker Reefing is all about the adventure Staff Member Team R2R R2R Supporter R2R Excellence Award Partner Member 2019 R2R Secret Santa Reef Tank 365 Build Thread Contributor Article Contributor

    Joined:
    Apr 11, 2015
    Messages:
    18,668
    Likes Received:
    34,579
    Location:
    Central Florida
    The mice thing about not gluing it I can now take it a part and clean the standpipe.

    GoVols, siggy, Fudsey and 1 other person like this.
  8. siggy

    siggy Gone Fishing Again R2R Supporter R2R Excellence Award Partner Member 2019 R2R Secret Santa Build Thread Contributor

    Joined:
    Feb 16, 2017
    Messages:
    3,508
    Likes Received:
    6,692
    Location:
    Chesterfield Michigan
    Ugh....OK

  9. jsker

    jsker Reefing is all about the adventure Staff Member Team R2R R2R Supporter R2R Excellence Award Partner Member 2019 R2R Secret Santa Reef Tank 365 Build Thread Contributor Article Contributor

    Joined:
    Apr 11, 2015
    Messages:
    18,668
    Likes Received:
    34,579
    Location:
    Central Florida
    You got me there;Hilarious;Hilarious but brilliant:p:D

  10. Crabs Mcjones

    Crabs Mcjones Millepora Maniac Staff Member Team R2R R2R Supporter R2R Excellence Award Partner Member 2019 R2R Secret Santa Reef Tank 365 Build Thread Contributor Article Contributor Hospitality Award

    Joined:
    Jul 24, 2017
    Messages:
    15,849
    Likes Received:
    59,203
    Location:
    Fond du Lac, Wisconsin

    GoVols, DSC reef, siggy and 1 other person like this.
  11. GoVols

    GoVols Cobb / Webb - 1989 R2R Supporter R2R Excellence Award Reef Squad Leader MTRCMember Partner Member 2019 Reef Tank 365 Build Thread Contributor Article Contributor

    Joined:
    Nov 29, 2016
    Messages:
    8,610
    Likes Received:
    21,253
    Location:
    In-The-Boro, TN
    @jsker

    Great thread and thanks for sharing!!

    :)

    jsker, Crabs Mcjones and Fudsey like this.
  12. jsker

    jsker Reefing is all about the adventure Staff Member Team R2R R2R Supporter R2R Excellence Award Partner Member 2019 R2R Secret Santa Reef Tank 365 Build Thread Contributor Article Contributor

    Joined:
    Apr 11, 2015
    Messages:
    18,668
    Likes Received:
    34,579
    Location:
    Central Florida
    Always a learning experience, thank you for the shout out Freddie;Happy

    Fudsey, Crabs Mcjones and GoVols like this.
  13. JBKReef

    JBKReef Valuable Member R2R Supporter R2R Secret Santa Build Thread Contributor

    Joined:
    May 15, 2017
    Messages:
    1,238
    Likes Received:
    1,390
    Location:
    Burlington, KY
    Did you not even bother with the Durso? I've been contemplating a change with my cube build right now. I have the standard plumbing that came with my Marineland 93 reef ready tank but it is SO loud in my living room. Its functionally fine but acoustically horrible.

    There is a small hole drilled in the return line that is supposed to be a siphon break I believe but it shoots out water constantly and creates a very noisy atmosphere. And completely useless because the water drains back into the sump from that hole slowly until the water is flush with it.

    Everything still flowing quietly?

    jsker and GoVols like this.
  14. jd371

    jd371 Valuable Member

    Joined:
    Jun 26, 2015
    Messages:
    1,485
    Likes Received:
    1,305
    Location:
    Long Island, New York
    After setting up my 75g right next to where I watch TV I couldn't have a noisy overflow. I have an eshopps pf800 overflow and it was way too noisy out of the box. I made a Stockman Standpipe to quiet it down. The first one I made looked exactly like the one in the video above. I noticed that when cleaning the overflow and taking apart the standpipe that rubber O ring would leave a black residue on my hands. I don't think the water level ever reached that part of the Stockman where the rubber O ring sits, but I didn't want to take a chance of having whatever was coming off that rubber in the tank.
    I replaced that coupler and rubber O ring with the fitting below. It's snug enough to hold it's position on the PVC drain tube and I'm able to get rid of the rubber O ring.

    https://www.lowes.com/pd/Genova-3-4-in-dia-Adapter-CPVC-Fittings/3341714

    GoVols likes this.
  15. Salty.Reefer

    Salty.Reefer Well-Known Member

    Joined:
    Jun 5, 2016
    Messages:
    851
    Likes Received:
    938
    Location:
    San Clemente, California
    Here is the Durso I built. It’s 1.5in and uses a airline valve I found at Home Depot. Super quite but sometimes takes a little bit to start back up after turning off the return. No glue involved!
    930C5595-0283-4467-87E6-E1E85251CF90.jpeg F78510F6-0857-4E40-8503-95B506DBECB0.jpeg C791E276-1170-4512-A389-679D213CB205.jpeg 18BC5DA3-489D-4768-B24D-8E403FF2F945.jpeg

  16. siggy

    siggy Gone Fishing Again R2R Supporter R2R Excellence Award Partner Member 2019 R2R Secret Santa Build Thread Contributor

    Joined:
    Feb 16, 2017
    Messages:
    3,508
    Likes Received:
    6,692
    Location:
    Chesterfield Michigan
    I have the same tank but 75 g. I plugged the hole (salt creap) and put line lock check vales on the returns,

    jsker and GoVols like this.
  17. JBKReef

    JBKReef Valuable Member R2R Supporter R2R Secret Santa Build Thread Contributor

    Joined:
    May 15, 2017
    Messages:
    1,238
    Likes Received:
    1,390
    Location:
    Burlington, KY
    I have the same problem. Nothing scares me more than a power outtage when I'm not home. I would say 20-25% of the time the durso does not fire up quick enough and would overflow if I was not there to cut the return and wait for it to catch up.

    jsker, Salty.Reefer and GoVols like this.
  18. Salty.Reefer

    Salty.Reefer Well-Known Member

    Joined:
    Jun 5, 2016
    Messages:
    851
    Likes Received:
    938
    Location:
    San Clemente, California
    Wow I have never had it over flow but it gets uncomfortable. Never stopped it ether. Do you know what causes the problem?

    jsker likes this.
  19. JBKReef

    JBKReef Valuable Member R2R Supporter R2R Secret Santa Build Thread Contributor

    Joined:
    May 15, 2017
    Messages:
    1,238
    Likes Received:
    1,390
    Location:
    Burlington, KY
    I do not, and its so random when it does or doesn't work. I have not been able to 1) isolate the problem, or 2) make the problem repeat

    My waterline is about an inch below the rim of the tank normally but when the return is shut off for feeding or water changes it either works as it should or begins to raise up the glass. I usually have about 20 second to catch it if it fails...

    jsker likes this.
  20. Salty.Reefer

    Salty.Reefer Well-Known Member

    Joined:
    Jun 5, 2016
    Messages:
    851
    Likes Received:
    938
    Location:
    San Clemente, California
    Hopefully mine dosnt overflow one day. Making me nervous lol

    jsker likes this.
