Skimmer Information for Database Members Input Needed

Discussion in 'General Equipment, Hardware, Filtration' started by Reefing Madness, May 7, 2013.

  1. BedrockIOMC

    BedrockIOMC Well-Known Member R2R Supporter Partner Member 2019 Build Thread Contributor

    Joined:
    Jul 3, 2018
    Messages:
    733
    Likes Received:
    576
    Location:
    Knoxville
    I dont have a sump on my freshwater. I done more research and decided I'm going to go this route.


  2. greg 45

    greg 45 Active Member

    Joined:
    Mar 14, 2010
    Messages:
    345
    Likes Received:
    137
    Location:
    bayonne new jersey
  3. reeftivo

    reeftivo skim junkie R2R Supporter

    Joined:
    Apr 26, 2010
    Messages:
    305
    Likes Received:
    112
    Location:
    Chino, California
    delete


  4. reeftivo

    reeftivo skim junkie R2R Supporter

    Joined:
    Apr 26, 2010
    Messages:
    305
    Likes Received:
    112
    Location:
    Chino, California
    sorry Mods

    i didn't want to post the retailers site and switched pictures and info, but it won't edit. the pic stays up.

    Hopefully it wont be an issue

    apologies

  5. reeftivo

    reeftivo skim junkie R2R Supporter

    Joined:
    Apr 26, 2010
    Messages:
    305
    Likes Received:
    112
    Location:
    Chino, California
    i wanted to post this

    I purchased an INS80S a while ago and it is a fierce performer. Old design but the design has been copied by others over and over because it flat out skims.

    There is overstock available and the sicce pumps are still readily available in case a replacement is needed.
    [​IMG]

    INS80S SPECS:
    The INS80S protein skimmer is rated to filter up to a 120 gallon marine aquarium, 80 gallon aquariums that are heavily stocked with live coral. Welded together with thick durable acrylic and PVC parts by American workers, you know the quality will be unmatched. The INS80S includes the protein skimmer body, protein skimmer cup and lid, collection cup quick-lock, the 1 1/4" adjustable outlet assembly, 1 1/4" air silencer, modified Sicce PSK pump with venturi and 2 feet of air hose, pump outlet fitting, and an air adjustment valve. This will be the last protein skimmer you will ever need for your home reef aquarium.
    • Sump Space Required For Skimmer/ Footprint: 9" x 9"
    • Minimum Height Required: 22"
    • Ideal Water Level: 6.5" Constant
    • Reaction Chamber & Cup Diameter: 5"
    • Reaction Chamber Volume: 1.02 Gallons
    • Pump Inlet Size: 3/4"
    • Water Outlet Size: 1¼"
    • Pump (included): Modified Sicce Pin-Wheel Pump
    • Pump Consumption With Maximum Air Intake: 17 Watts @ 115/120 VAC 60hz
    • Air Intake: 360-480 lph

    INS135S Specs:

    The INS135S protein skimmer is rated to filter up to a 250 gallon marine aquarium, 135 gallon aquariums that are heavily stocked with live coral. Welded together with thick durable acrylic and PVC parts by American workers, you know the quality will be unmatched. The INS135S includes the protein skimmer body, protein skimmer cup and lid, collection cup quick-lock, the 1 1/4" adjustable outlet assembly, 1 1/4" air silencer, modified Sicce PSK pump with venturi and 2 feet of air hose, pump outlet fitting, and an air adjustment valve. This will be the last protein skimmer you will ever need for your home reef aquarium.
    • Sump Space Required For Skimmer/ Footprint: 10" x 11.5"
    • Minimum Height Required: 24"
    • Ideal Water Level: 7" Constant
    • Reaction Chamber & Cup Diameter: 6"
    • Reaction Chamber Volume: 1.47 Gallons
    • Pump Inlet Size: 1"
    • Water Outlet Size: 1¼"
    • Pump (included): Modified Sicce Pin-Wheel Pump
    • Pump Consumption With Maximum Air Intake: 26 Watts @ 115/120 VAC 60hz
    • Air Intake: 720-780 lph

  6. Crabs McJones

    Crabs McJones Millepora Maniac Staff Member Team R2R R2R Supporter R2R Excellence Award Partner Member 2019 R2R Secret Santa Reef Tank 365 Article Contributor Glitter Fairy Hospitality Award Build Thread Contributor

    Joined:
    Jul 24, 2017
    Messages:
    17,646
    Likes Received:
    70,579
    Location:
    Fond du Lac, Wisconsin
    Sorry if this is already in here:
    Reef Octopus Classic 110INT skimmer
    Recommended for tanks up to 100 gallons with medium bioload
    75 Gallons for heavy bioload
    10.6" x 6.75" x 19.75" footprint
    Aquatrance 1000 pump with pinwheel impeller
    Max Flow:92gph
    Max Air:420L/H, 15SCFH
    Power Consumption: 9watts
    venturi air injection system
    Gate valve for adjustment
    Recommended water height of 5 to 7 inches
    [​IMG]

  7. Finless

    Finless Member

    Joined:
    Nov 15, 2018
    Messages:
    24
    Likes Received:
    131
    Skimz SN143-QP Monzter mini

    Diameter: 5 1/2"

    Foot print: 7 9/16" x 7 7/8"

    Pump: Skimz QPS2.ODC
    528gph @22w

    Air intake: 240-660L/h

    Impeller: Needle

    Recirculating pump: NO

    Tank size: 40g (heavy stock) to
    120g (light stock) SmartSelect_20181116-005453_Samsung%20Internet.jpeg

  8. reeftivo

    reeftivo skim junkie R2R Supporter

    Joined:
    Apr 26, 2010
    Messages:
    305
    Likes Received:
    112
    Location:
    Chino, California
    These are not available right now in the states from what I've seen. Unique corals stocked them along with Manhattan Aquariums but they don't currently list on their sites. I ordered mine direct from Ultrareef Italy after contacting the owner on line. The price for these is about a wash if you bought in the states-vs- direct from Italy. The skimmers (UKS 160, 180 and 200) are cheaper over seas but with the shipping from Italy, they come out right around the same cost.
    These are built as good as Bubble kings (owned BKs) and all PVC is machined from full blocks of PVC. they are heavy-beefy skimmers, practically silent and have HUGE cups. this is the best performing skimmer I've owned next to my ATB econo 840 with askoll/airstar pump.

    [​IMG]
    AKULA UKS-160
    SKIMMER
    Aquariums size200 - 500 litPumpUltra Reef PSK 600+Air intake ~ 500 - 600 lit/hWater intake~ 1000 lit/hPower consumption~ 22 WDimensions17x23 cm (6.7x9.1”)Height56 cm (22”)
    Note
    To be installed in sump, water level 18-22 mm (7-8.6“)Standard power 230-240V 50Hz, on request 110-120V 60Hz
    How it works
    The Ultra Reef AKULA UKS range of protein skimmers is a method of filtration that allows
    the removal of the organics from seawater. It pumps a mixture of aquarium water and
    air bubbles into a mixing chamber. By exploiting the properties of the film surface tension
    between air and water, it generates a foam overflowing from the main chamber, and then
    into a collection cup which allows for easy removal.
    PRODUCT FEATURES

    Modern design and low power consumption
    The internal pump design is the most compact solution you could have for your aquarium. The pump is housed directly inside the main chamber to reduce the lateral ingots. To access the pump just remove the locking screws and lift off the conical chamber. Skimmers water intake is direct, so it is not necessary to use a feed pump. This solution significantly reduces power consumption and maintenance time.
    Particular attention to silence:
    The rubber feet absorb all annoying vibrations. To silence the suction of the air, the skimmer is complete with a built-in silenced muffler to absorb the noise produced by the venturi. The exhaust/effluent system is housed on the base and submerged to avoid any noise from the water returning to the system.
    Performance and reliability with Ultra Reef PSK+ Plus skimming pumps.
    The new Ultra Reef PSK+ Plus needle wheel pump is exclusive to Ultra Reef. This is a dedicated model of the famous PSK pump and is produced for Ultra Reef by Sicce. It is designed to produce the best air and water emulsion through a needle wheel impeller. The transparent body allows pump inspection even during operation, while reinforced impellers allow superior performance and strength.
    Easy adjustment, stable and accurate regulation.
    The conical body is made from cast acrylic designed to improve internal flow and create homogenous thrust throughout the entire body, the shaped diffusion cup improves the separation of air and water, ensuring excellent stability even from the first start. Internal level adjustment is carried out through a screw valve and the silencer has the added flexibility of an adjustment screw to set the maximum amount of air intake.
    Innovative Easy-Flip gasket system
    Collection cup and internal neck feature an "Easy Flip" seals for a firm grip and easy removal during maintenance. For ease of maintenance the neck of the cup can also be removed for easy cleaning.
    Easy and thorough maintenance
    Our product can be disassembled virtually in every single component. The generous thicknesses of the materials used ensure excellent resistance during all maintenance, while small component reduction facilitates cleaning and replacement of individual worn components.
    DESIGN, QUALITY AND PERFORMANCE

    Italian design and production
    We perform all of the internal development of our products in house, from design to production. Our brand guarantees a deep and careful evaluation of the operation, both technically and aesthetically, thanks to the CNC machining of full blocks of PVC
    ISO 9001 Quality certification
    The goal of business excellence can be achieved only if production processes are continuously improved. Our company is certified and complies with the ISO 9001, the most commonly used international standard that provides a framework for Quality Management Systems.
    Viti anticorrosione in Titanio
    Screws DIN7985 are made in Titanium G2, resistant to corrosion caused by seawater.To give the best even in smaller components.

    Last edited: Dec 21, 2018
  9. FLSharkvictim

    FLSharkvictim Marine Conservationists R2R Supporter Tampa Bay Reef Keepers Build Thread Contributor West Palm Beach Reefer

    Joined:
    Oct 11, 2016
    Messages:
    1,310
    Likes Received:
    995
    Location:
    Redington Beach, FL
    I like running these Reef Octopus OCTO Regal 150-INT In-Sump Protein Skimmers w/ a Float switch and there controllers.
    • For aquariums up to 210 gallons with a light filtration demand. For aquariums up to 160 gallons with a medium filtration demand. For aquariums up to 100 gallons with a high filtration demand.
    • Small Footprint: 11.4" x 7.5", Body Diameter: 6", Height: 22.6"
    • Reef Octopus VarioS-2S Controllable Pinwheel Pump. Latest in DC controllable technology. Pump has 5 controllable energy efficient power setting
    • Output Size: 40mm - Comes with metric to British adapter to 1.25” pvc ; Output Height: 9.1"
    • Recommended Sump Water Depth: 6" to 8"

    Regal 150.JPG Regal INTL #6.JPG
    [​IMG]

    Reefing Madness likes this.
  10. Zan101

    Zan101 Member

    Joined:
    Nov 3, 2018
    Messages:
    64
    Likes Received:
    17
    Has any used the icecap protein skimmers

  11. Oldsalt

    Oldsalt Active Member

    Joined:
    Dec 6, 2018
    Messages:
    218
    Likes Received:
    302
    Location:
    Perth Western Australia
    If you want a fresh water skimmer, Google "Sander protein Skimmer" . They make them for virtually anything, including water treatment. They have the fresh water skimmers listed as well. Some of the skimmers they make are taller than a 3 storey building!! They put a 6 foot human next to the skimmer to give you an idea of the sheer size. I had one of the 1st marine tank skimmers they made in the 80's. All air driven with "ozonereaktor" on the cup top. Here's a photo. I only use it on a QT and swap it between that and the fry raising tank.

    For my 340 gallon I just bought a Bubble Magus Curve 9 plus (DC). I will post separately about it for the database, but so far it's fantastic.

    I also have an old Marine Sources with Hailea pump that I pulled out when putting in the Curve 9 plus DC. I'll post that one separately as well. It ran ok but microbubbles were a never ending battle - changing black outlet socks frequently.



  12. nano24Clownfish

    nano24Clownfish Member

    Joined:
    May 10, 2017
    Messages:
    34
    Likes Received:
    25
    Made in Austria? If it's the equivalent of the Gock of protein skimmers, that may be my next purchase. Like, you can use the collection cup of a 150 on the 250, but not vise versa. Those little tricks that make it more modular and save money if you do your research. lol

  13. Nep2nRev1

    Nep2nRev1 Active Member R2R Supporter Build Thread Contributor

    Joined:
    Jan 13, 2019
    Messages:
    140
    Likes Received:
    195
    Location:
    Timberlake, NC
    Vertex Alpha 250.JPG 250 Specs.JPG
    I'm running this on a system with total water volume of +/- 300 g. In sump skimmer, needs stable water level. Runs quietly. Touchy to dial in but very effective once set. Very happy this skimmer.

  14. Retro Reefer

    Retro Reefer Older than dirt! R2R Supporter R2R Excellence Award Reef Tank 365 Hospitality Award Build Thread Contributor

    Joined:
    Dec 15, 2015
    Messages:
    4,096
    Likes Received:
    18,785
    Location:
    Manassas Va
    Coralbox 300+ DC skimmer

    I have owned probably a dozen skimmers over the years from various manufacturers and I have to say I’m absolutely blown away with the quality and performance of the coralbox skimmers for the money.


    The 300+ pictured above is super compact and rated for tanks from 30 to 120 gallons.


    The new CoralBox D300+ Protein Skimmer has a built in float switch, and adjustable feed time. The D300+ is powered by a CoralBox DCA1,200 pump with a needle-wheel impeller for maximum aeration, and a controller with an integrated float switch. The air input, water output, and pump speed are all adjustable. You can set a 10 minute, 20 minute, or 50 minute feed time with the touch of a button.

    The pump has 6 output settings that are controlled with an included controller, or can be controlled with an aquarium controller and the proper hardware. The pump has a soft-start function as well, being that it is DC powered, the controller will start it off at a low speed, and slowly ramp it up to the speed you set to prevent overflows on startup.

    The Coral Box D300+ Skimmer has a base diameter of 5 3/4″ and a height of 17 3/4″ with the cup.




    These skimmers can be completely disassembled for easy cleaning and maintenance.




    Running mine in a small eshopps RS75 sump which provides filtration on a 40 breeder.. some of my favorite features are the large collection cup with auto shut off float switch, gate valve and controllable pump for easy precise tuning, super small footprint and the ease of maintenance.



    This skimmer is a absolute beast.. it’s super quiet, easy to tune and started producing skimate right away.



    You can currently find this skimmer on Reefbreeders for $219.00 and I can confidently say it will preform as well or better than any similar sized skimmer from any manufacturer regardless of the price.

    Oldsalt likes this.
  15. Oldsalt

    Oldsalt Active Member

    Joined:
    Dec 6, 2018
    Messages:
    218
    Likes Received:
    302
    Location:
    Perth Western Australia
    I wanted the Coral Box D 700. It would have handled my 1500 litre tank (~330 gallons) including sump well but 2 things got in the way.
    1 - too big for my sump without major modifications including cutting glass and chopping part of the aluminium stand (sump was pre-fab and pre-installed). The price is amazing for the features. Then there is the same brand Cloud 9. Also too big.
    2 - I couldn't find anyone who could get one to me without exorbitant shipping fees, import duty and a long wait (I needed a skimmer "yesterday") . I live in Perth Western Australia.

    I thought about pulling out the sump and making major changes to it but it's all set up with a fuge that's very stable. It's a shame because they're excel skimmers at a great price. Oh well, it is what it is...

    OK . Info for the database:

    I was running an ancient Marine Sources (photo attached) skimmer with an AC Hailea pump and ozone injector. It did a reasonable job but, by (poor?) design, outputted copious quantities of micro bubbles that required constant fidgeting with either outflow socks or foam. The socks got black in little time. The foam had little effect so I had to make a baffle of plastic to prevent the bubbles re-entering its pump. The Hailea pump put out too much heat and used too much power. I can't find information for this skimmer. I bought it 2nd hand for $200.00 Australian (about $150.00 US) from a local hobbyist. If anyone knows anything about this old Marine Sources skimmer, feel free to chime in.

    So I settled for Bubble Magus Curve 9Plus with internal DSP 4000 DC pump. It fit in my sump like a glove. Uses very little power and performs extremely well. Unlike Bubble Magus earlier Curve 9 with AC pump that was super noisy, this one is whisper quiet - I think the company noticed all the complaints about that and changed to DC. At $529.00 Australian (about $400.00 US) and zero shipping or tax (the price you see is the price you pay here because price is tax inclusive), it fit my budget well and I only had to drive for 20 minutes to pick it up.
    It only took 2 or 3 days to break in. No micro bubbles, excellent skimmate production, very little heat and noise, super easy to set - the sweet spot water level seems best at ~ 9" (the company states 9.5" to 11"). My skimmer chamber water level is a quarter inch over 9", so I didn't need a stand. It's super easy to take apart to clean. Has a 2 year warranty + 1 extra year from my LFS.
    I'm very happy with it so far..

    https://oceanreefsmarine.com.au/products/bubble-magus-curve-9-protein-skimmer

    My own photo attached as well as the advertisement from my LFS above.



    Last edited: Mar 13, 2019
