When I was setting up my lights I had a hard time finding recommended settings except for the pre loaded profiles. I figured I would create a thread where we can share our profiles and discuss. My light profile attached is a 12 hour schedule. Ramp up is 4 hours, peak is 4 hours, and ramp down is 4 hours. The first and last hour is heavier on blue. lights are 9.5' off the water surface off a 21" deep tank. I get 100-150 par on the bottom and 200-250 par on the highest rock surface in the upper 2/3rds of the tank. I have had good luck growing SPS, LPS, and the Nem in my profile pic.


Attachments

Silver14SS

Valuable Member
View Badges
Joined
Apr 8, 2017
Messages
2,401
Reaction score
4,237
Location
Charlotte, NC area
OP
b4tn

b4tn

Valuable Member
View Badges
Joined
Jun 17, 2015
Messages
1,605
Reaction score
2,107
Location
Columbia MD
I have had my settings here for almost a month now and think this is my final setting. SPS are all displaying lots of PE and coloring up very well. My clam is super happy and has massive growth rings as well. Tank gets 4 hours of full power and 8 hours of ramping. Average across the the rock work is 250-300 and bottom is pretty even at 200 with my screen top on.

Specifics:

- Pics taken with an iphone 11 pro with the orphek orange lens

- Reef is 7 months old

- Tank is 48" by 18" deep and 18" wide

- Two Reefi duo extremes 9.5" from the surface with a screen top on.

-Rock work is 6” below rhe

- PAR meter is an Apogee SQ-520

- I did not do the UV correction so numbers are probably a bit higher.

- Total ramping time including one hour in the morning and 1 hour at night of just blues is 4 hours up, 4 hours full intensity, then 4 hours ramping down.

I struggle with the PAR in the upper center of my tank due to the center brace. I did replace the brace with lexan and it helped a little but not much. I also raised the lights to 12" to even out the spread a bit more and it did help a little but the light spill in front of the tank was not worth it so I brought them back down.




Attachments

Corals.com

Wtyson254

Active Member
View Badges
Joined
Jun 14, 2011
Messages
326
Reaction score
193
Location
New York
Does anyone have any setting that Mirrow AB+? Or potentially kelvin temp based settings? I think a 12k, 14k, 18k,
And 20k default would be a nice addition to the default settings @danlu_gt


danlu_gt

Active Member
View Badges
Joined
Aug 22, 2014
Messages
144
Reaction score
272
Does anyone have any setting that Mirrow AB+? Or potentially kelvin temp based settings? I think a 12k, 14k, 18k,
And 20k default would be a nice addition to the default settings @danlu_gt
To me the kelvin temp do not make sense for LEDs that you can control individual color channels. Traditional MH/T5, the kelvin temp is overall blend of "white" light but just how cool or warm the white light is. With today's LEDs, you can controls the blues to UV channels independent to the "warmer" colors. So you can give your corals all the blues to UVs for growth and color, then just add the "warmers" leds to your liking without affecting the blues to UV intensity. Just going by kelvin temp for LEDs, it's possible to adjust the settings such that there are more blue to UV PARS at 12K than at 20K.

Top Shelf Aquatics

Wtyson254

Active Member
View Badges
Joined
Jun 14, 2011
Messages
326
Reaction score
193
Location
New York
To me the kelvin temp do not make sense for LEDs that you can control individual color channels. Traditional MH/T5, the kelvin temp is overall blend of "white" light but just how cool or warm the white light is. With today's LEDs, you can controls the blues to UV channels independent to the "warmer" colors. So you can give your corals all the blues to UVs for growth and color, then just add the "warmers" leds to your liking without affecting the blues to UV intensity. Just going by kelvin temp for LEDs, it's possible to adjust the settings such that there are more blue to UV PARS at 12K than at 20K.

I understand what you are saying, but I think for a lot of people, having a 12k,14k (based on visual appearance) preset could
Help those who are a bit overwhelmed by the 9 channels of control. I like the default presets you have, but I do find them to be too blue for my personal liking. I was able to create a “14k” look, but it took some time. I also don’t know what the best proportion of the different blue wavelengths to each other so I currently have them all maxed out and adjusted the non-blue channels to visual effect, then turned down the master intensity.


fragit

Valuable Member
View Badges
Joined
Nov 21, 2012
Messages
2,239
Reaction score
1,678
Location
Freeport, Maine
I understand what you are saying, but I think for a lot of people, having a 12k,14k (based on visual appearance) preset could
Help those who are a bit overwhelmed by the 9 channels of control. I like the default presets you have, but I do find them to be too blue for my personal liking. I was able to create a “14k” look, but it took some time. I also don’t know what the best proportion of the different blue wavelengths to each other so I currently have them all maxed out and adjusted the non-blue channels to visual effect, then turned down the master intensity.
That’s basically what you do but you (I’m included) should check par levels and adjust master from there. This is at least what the BRS guys have been doing. It seems credible to me. I just used SunCrest’s schedule and tweaked it a little to fit my time needs, color and boost power for hanging height. I agree presets are just a bit blue for me. I think if you set the color you like and adjust and pay attention to total wattage of other people with similar set ups and par settings you can make an educated guess of what you need. However a par meter is the only way to know for sure.
