Buckle up my children.
February 2023
I welcome your comments, excitement, criticism, and assistance!
February 2023
I welcome your comments, excitement, criticism, and assistance!
I recently moved to Pennsylvania from Baltimore in summer 2022 which required breaking down my tanks and starting with no livestock in my new house.
I set up my frag system in the fall of 2022 along with the accompanying frameless cubes for clown pairs. Here’s what that system looks like.
![843141cc6e4021e22b8b23ebfdea0822.jpg 843141cc6e4021e22b8b23ebfdea0822.jpg](/proxy.php?image=https%3A%2F%2Fuploads.tapatalk-cdn.com%2F20230228%2F843141cc6e4021e22b8b23ebfdea0822.jpg&hash=5e72c1df51aa6a563e1369503828d350)
This build thread will be about my new fish room which includes the frag system, but more importantly the Reef 180.5 that I picked up from Trevor (WAMAS member) in February 2023.
Simply put, my new house is too nice for me to put a saltwater system in the upstairs living space. I know that I will ruin the flooring through some mistake at some point, so everything is staying in the basement.
With the help from Trevor and a few friends with borrowed suction cups we drove down to Maryland and picked up the system, which included:
Waterbox Reef 180.5
Stand
Plumbing and Sump
Apex A2
KH Guardian
MP40
2x Heaters with inkbird
Duetto ATO
Getting it into the truck required stand disassembly and creative thinking but we made it back, reassembled the stand, and set the tank in place. We also moved an even heavier Innovative Marine NUVO 170 EXT on the same day which I almost dropped. Luckily almost dropping it doesn’t count and all ended well.
Here’s the tank:
![405991538533203517b532de030c7dfe.jpg 405991538533203517b532de030c7dfe.jpg](/proxy.php?image=https%3A%2F%2Fuploads.tapatalk-cdn.com%2F20230228%2F405991538533203517b532de030c7dfe.jpg&hash=8392b78bb8e85c17596f9563c3bb317a)
Let’s build a wall.
I started by calling the township to figure out some rules for building rooms in my basement. No bedroom, no rules. So here goes!
Here is a simple 2x4 wall construction with a door to split the basement in half. I started by using construction adhesive to attached a 2x6 to the beam, then hung a plumb bob and snapped a few chalk lines. I need to get a laser level…
![0cdfb39187e8a5ecadbad134211e26fc.jpg 0cdfb39187e8a5ecadbad134211e26fc.jpg](/proxy.php?image=https%3A%2F%2Fuploads.tapatalk-cdn.com%2F20230228%2F0cdfb39187e8a5ecadbad134211e26fc.jpg&hash=679f3acd08b3939031a9a47e60908b3c)
Let’s add water!
![2762d23542e01e2d583946c1d084fef4.jpg 2762d23542e01e2d583946c1d084fef4.jpg](/proxy.php?image=https%3A%2F%2Fuploads.tapatalk-cdn.com%2F20230228%2F2762d23542e01e2d583946c1d084fef4.jpg&hash=b79c54aa060da4c62d1d28a6288be5a2)
I was amazed that the glass seamlessly disappeared as the tank filled. See thumb. Ha.
![6df231acfdc37ce6a0bbdb414caa2d89.jpg 6df231acfdc37ce6a0bbdb414caa2d89.jpg](/proxy.php?image=https%3A%2F%2Fuploads.tapatalk-cdn.com%2F20230228%2F6df231acfdc37ce6a0bbdb414caa2d89.jpg&hash=d92c7207a20ae3804636b1f712632fc2)
Did I mention that there is currently no plumbing assembled because Waterbox is Metric? In order to plumb the remote sump I purchased bulkheads to convert to standard plumbing. They are currently stuck in Memphis at FedEx for the last three days (Today is 2-28-2023).
![5a0190a74c1ef11a505c5d18ca5a161c.jpg 5a0190a74c1ef11a505c5d18ca5a161c.jpg](/proxy.php?image=https%3A%2F%2Fuploads.tapatalk-cdn.com%2F20230228%2F5a0190a74c1ef11a505c5d18ca5a161c.jpg&hash=1efedb3af96631080f4023a63e944288)
Let’s add heat, salt, rocks, live sand, and bacteria. Still no plumbing.
Don’t you love this Silent Hill…into the fog look? I do.
![d96b2fcfe8b1954847fb5910946aa3f3.jpg d96b2fcfe8b1954847fb5910946aa3f3.jpg](/proxy.php?image=https%3A%2F%2Fuploads.tapatalk-cdn.com%2F20230228%2Fd96b2fcfe8b1954847fb5910946aa3f3.jpg&hash=407938fbd647da0aa3f4b128c149b4fb)
![6b4e3058ffe65287f0ad982c5d291e1d.jpg 6b4e3058ffe65287f0ad982c5d291e1d.jpg](/proxy.php?image=https%3A%2F%2Fuploads.tapatalk-cdn.com%2F20230228%2F6b4e3058ffe65287f0ad982c5d291e1d.jpg&hash=cacee87c2c9bc97af95cdcdc94219f75)
Just a reminder, water level is low due to lack of plumbing as parts are stuck with FedEx. I forgot to mention that this incredible scape also came from Trevor along with lots of other things. What do you think of it? Looks professional level to me. I stacked it on some Marco base rock that I had in my system.
![c2af14f6d1046f5c7fea6d14d96c4447.jpg c2af14f6d1046f5c7fea6d14d96c4447.jpg](/proxy.php?image=https%3A%2F%2Fuploads.tapatalk-cdn.com%2F20230228%2Fc2af14f6d1046f5c7fea6d14d96c4447.jpg&hash=d1f1aa44aef648b8f79199f3546733b7)
![5d850f279fc7e112cb06e4ca353cf4f9.jpg 5d850f279fc7e112cb06e4ca353cf4f9.jpg](/proxy.php?image=https%3A%2F%2Fuploads.tapatalk-cdn.com%2F20230228%2F5d850f279fc7e112cb06e4ca353cf4f9.jpg&hash=51c9e6556a2bedb42a6e503f49335b59)
Let’s talk sump and filtration. Here it is! Ha.
![5d88396775e2e3c7b45563e74a6e96c0.jpg 5d88396775e2e3c7b45563e74a6e96c0.jpg](/proxy.php?image=https%3A%2F%2Fuploads.tapatalk-cdn.com%2F20230228%2F5d88396775e2e3c7b45563e74a6e96c0.jpg&hash=24b53202664a3d3947d700310b5eedc6)
I am plumbing the sump outside of the cabinet for the health of the fish and my family, especially small children that stick their hands in everything and then in their mouth.
Extra bonus, limitless skimmer size!
Let’s talk electrical.
I am not an electrician and this is not advice.
I have a few spare 20 amp circuits on my panel so I ran some 12/2 in PVC conduit down the wall to a few boxes and installed a duplex outlet in a waterproof box INSIDE of the adaptive reef cabinet.
Here’s what that looks like in-progress. There is one outlet on the wall and one outlet in the cabinet.
Trevor also included an EB832 and EB8, so plenty of power that can plug into the outlet in the adaptive reef cabinet.
![8cef34da54627bc34ed5dc8e0dc7aebd.jpg 8cef34da54627bc34ed5dc8e0dc7aebd.jpg](/proxy.php?image=https%3A%2F%2Fuploads.tapatalk-cdn.com%2F20230228%2F8cef34da54627bc34ed5dc8e0dc7aebd.jpg&hash=d6869dfaae1c3a1d1dd417216a375658)
But what about a GFCI you ask? Once again, this is not electrical advice. I learn from YouTube and online schematics.
I wired a GFCI outlet as outlet number one in a Line/Load configuration so that all outlets are protected from the GFCI. All outlets are wired in parallel, sourced from the load side of the 20 AMP GFCI. Thoughts?
Illumination! I bought a 2-bulb T5 from David (WAMAS member) and he threw in a 55 gallon drum and a calcium reactor! What a guy!
I love LED’s but I’m addicted to the even blanketing spread of T5…none of which is pictured here haha.
For this tank I have 2 x 300 Watt Viparspectra lights. In my opinion they are the best of the black boxes and will smoke your acros overnight if you aren’t careful. Yes, I know about the lens mods, no I don’t plan to crack them open. Pictured is a single fixture at 100% for both channels.
![09bafa470d98bea49c3cad1ea9a2e224.jpg 09bafa470d98bea49c3cad1ea9a2e224.jpg](/proxy.php?image=https%3A%2F%2Fuploads.tapatalk-cdn.com%2F20230228%2F09bafa470d98bea49c3cad1ea9a2e224.jpg&hash=f1f06e7cdef4f3f7bff892b296f1a3d7)
Same light with Orphek lens filter on my phone.
![f900d90b8910b6e0d1a77ebaa7c6cac5.jpg f900d90b8910b6e0d1a77ebaa7c6cac5.jpg](/proxy.php?image=https%3A%2F%2Fuploads.tapatalk-cdn.com%2F20230228%2Ff900d90b8910b6e0d1a77ebaa7c6cac5.jpg&hash=441921e03e12bb2cee5ea95ae582c443)
And lastly, the T5 from David (pictured top left) that will also be over this tank but is currently nourishing a couple rose BTA’s in the clown cubes. (Orphek lens filter used).
![60f82c003ddbf78b807f6198115eba5f.jpg 60f82c003ddbf78b807f6198115eba5f.jpg](/proxy.php?image=https%3A%2F%2Fuploads.tapatalk-cdn.com%2F20230228%2F60f82c003ddbf78b807f6198115eba5f.jpg&hash=ebd072aad546e867c52054dad644a6f9)
